AWA2581 Outdoor Noise Monitoring Box
AWA2581 Outdoor Noise Monitoring Box AWA2581 Outdoor Noise Monitoring Box AWA2581 Outdoor Noise Monitoring Box AWA2581 Outdoor Noise Monitoring Box
AWA2581 Outdoor Noise Monitoring Box
Material: Engineering Plastic
Size: 460*360*130mm
Weight: 5kg
Ingress protection: IP65
Max. length of extension rod: 1.7m
Download
Get A Quote
Please select the operation you need
preview
Download
Aihua Instruments Aihua Instruments
Key Features Product Uses Technical Specifications
Key Features

◆ Easy to use, no manual operation required

◆ The outdoor wind shield is windproof, rainproof, and bird-proof, eliminating worries about wind and rain.

◆ The high-strength waterproof case is made of reinforced engineering plastic, offering advantages such as high strength, light weight, waterproofing, dustproofing, and corrosion resistance.

◆ The extension rod is made of fiberglass, lightweight, and telescopic. It can be stored inside the case when folded, and its extended height is approximately 1.7 meters.

◆ Uses an AWA1721 lithium-ion battery pack, providing 50-130 hours of continuous operation. Solar panel charging is also available, with a maximum output of 10W.


Technical Specifications


    Product Model

    AWA2581 Outdoor Noise Monitoring Box

    Enclosure protection level

    IP65

    Anti-theft design

    Users can lock

    Extension rod length

    About 1.7 meters

    Backup battery

    AWA1721 lithium-ion battery pack

    Battery usage temperature

    Charging: 0℃～50℃


    Discharging: -20℃～60℃


    Storage: -20℃～45℃


    Applicable instrument models

    AWA6228+、AWA5688

    Outdoor windshield

    The AWA14803 model is suitable for Class 1 sound level meters.


    The AWA14805 model is suitable for Class 2 sound level meters.


    Box dimensions（mm）

    460×360×130

    Gross eight

    5.5kg

    Solar charging function (optional)

    The solar panel has a maximum output of 10W.
