AWA5636 Sound Level Meter Kit
AWA5636 Sound Level Meter Kit AWA5636 Sound Level Meter Kit AWA5636 Sound Level Meter Kit AWA5636 Sound Level Meter Kit
AWA5636 Sound Level Meter Kit
Please select the operation you need
Aihua Instruments Aihua Instruments
Key Features


■  Supplied with printer, calibrator and case

■  Clearly LCD display, portable, compact and simple to use

■  Prints noise level results on site with date and time of complaint response

■  Wireless printing mode

Product Uses


■  Widely use in Industrial Noise Surveys; machinery, vehicles, ships and etc.

■  For Community Noise Ordinance Measurements and Nuisance Complaint Response.



Technical Specifications

    Measurement Kit:

    Including:

    ● AWA5636-4 Sound Level Meter*1

    ● AWA6022A Sound Calibrator *1

    ● AH58F High Speed Dot Matrix Printer*1

    Sound Level Meter Specifications

    Dimensions

    210×65×27 mm

    Standards

    IEC 61672-1:2002 Class 2

    Accuracy

    Class 2

    Application

    Sound Level Meter / Noise Dosimeter

    Frequency

    20 Hz ~ 12.5 kHz, Weighing A,C and Z weightings

    Power Supply

    Lithium Battery and Battery life: over 30 hours of continuous use when fully charged.

    Product weight

    240gms

    Measurement Range

    30 to 140 dB

    Display

    128x64 OLED

    Display Resolution

    0.1dB

    Calendar clock

    Date and Time are displayed

    Frequency Weighting

    A, C and Z weightings : F, S Impulse weighting peak

    Measurements

    Sound Level Pressure (SPL) Min., SPL. Max., Leq.,Sound Exposure Level (SEL) with Date & time and Run Time continuously available on the displayLFp, LSp, Lip, Leqt, Lpeak, Leq,T, Lfmax, Lfmin, Lsmax, Lsmin,Limax, Limin, SEL,Lex8h, LAVG, TWA, DOSE, L5,L10,L50,L90,L95, SD, Ts, Tm, Volt, Date, Time, E.

    Operation Mode

    Both in PAUSE mode & in RUN mode instrument displays SPL. Min.,SPL Max, in RUN mode measure instantaneous reading and convert them to Leq and send the data to battery operated portable printer and prints SPL. Min., SPL. MAX. and Leq

    Memory Capacity

    Built-in memory 2 GB, stores 8000 groups measurement results or continuously store more than 500 hours.

    Temperature

    Air Temperature : -10 deg C +50 deg C

    Relative Humidity : 5 % - 95%

    Air Pressure : 65 kPa – 108 kPa

    Notes

    USB port download data to PC and for recharging. Adjustable Criterion Level, Exchange Rate and Threshold,Integrating time: 1s-24h
