AWA14601 Wideband TEDS-Enabled Preamplifier
Preamplifier
From Sound Level Meters and Acoustic Imagers to Calibrators and sound level sensor for professional testing and research.
Inquiry Now
AWA14601 Preamplifier01.jpg
AWA14601 Preamplifier02.jpg

AWA14601 Wideband TEDS-Enabled Preamplifier

Reference-grade measurement accuracy: ultra-wide, flat frequency response combined with near-zero insertion loss and ultra-low distortion make it suitable for high-precision acoustic metrology and calibration work

Low-noise performance for weak signal detection: microvolt-level self-noise enables accurate measurement of very low sound pressure levels

High dynamic range: strong output drive capability (≥10 Vrms) supports measurement of high-level acoustic events without clipping

Robust environmental adaptability: extended temperature range with tight accuracy tolerances ensures reliable performance in harsh field and industrial conditions

Ideal for demanding applications: well-suited for high-end acoustic research, precision noise/vibration testing, environmental monitoring, and standards-compliant calibration laboratories

    • prod_icon_03
      Class 1SLM
    • prod_icon_05
      Mobile App
    • prod_icon_07
      IEC61672
    Contact us
    icon1Descriptionvideo_fillProduct Videoicon2 Featuresicon3Performance
    product details
    AWA14601 Preamplifier02
    01

    Product Description

    The AWA14601 preamplifier is a specialized amplifier characterized by high input resistance, low input capacitance, and low output impedance; it is designed to operate with measurement microphones to perform impedance transformation and pre-amplification.

    Product Video

    Features

    1/2" (Φ12.7mm) form factor — compatible with standard 1/2" measurement microphone capsules
    Ultra-wide frequency response: 20 Hz–200 kHz (±0.1 dB); 5 Hz–200 kHz (±0.5 dB)
    Extremely high input impedance: ≥2 GΩ, with ultra-low input capacitance ≤1 pF
    Ultra-low output impedance: ≤50 Ω
    Minimal insertion loss: transmission gain of only -0.1 dB
    Very low distortion: THD ≤0.1%
    High output drive capability: ≥10 Vrms @ 45 V supply
    Low self-noise: A-weighted ≤3 μV, Z-weighted ≤7 μV (20 Hz–20 kHz)
    Wide operating temperature range: -40°C to 60°C (±0.1 dB); -40°C to 80°C (±0.3 dB)
    TEDS supported (IEEE 1451.4 transducer electronic data sheet)

    Main Performance Indicators

    AWA14601 Preamplifier

    Size

    Φ12.7mm(1/2")

    Frequency response

    20Hz～200kHz±0.1dB; 5Hz～200kHz±0.5dB

    Transmission gain

    -0.1dB

    Input impedance/capacitance

    ≥2GΩ/≤1pF

    Total Harmonic Distortion (THD)

    ≤0.1%

    Output impedance

    ≤50Ω

    Output voltage

    ≥10 Vrms @ 45 V supply

    Polarization voltage

    0V

    TEDS

    Supported

    Power supply

    9V～45V

    Output interface

    X9-6T2

    Self-noise

    A-weighted: ≤3 μV; Z-weighted: ≤7 μV (20 Hz–20 kHz)

    Temperature range

     -40°C to 60°C ±0.1 dB; -40°C to 80°C ±0.3 dB
