AWA14434 1/4" High-SPL Pressure-Field Microphone
Ultra-high sound pressure capability (>175 dB): Designed specifically for extreme SPL measurement applications, ideal for high-intensity acoustic environments.
Wide dynamic range (57–175 dB): Ensures accurate measurement from moderate to extremely high sound pressure levels.
High-frequency performance (up to 40 kHz): Supports wideband acoustic analysis including ultrasonic and high-frequency noise testing.
Stable engineering-grade design (SJ/T 10724 Class 1): Meets engineering measuring microphone standards with strong stability and environmental adaptability.
Compact 1/4-inch structure for high SPL applications: Optimized small diaphragm design reduces overload risk while maintaining measurement accuracy in extreme conditions.
-
Class 1SLM -
Mobile App -
IEC61672
01
Product Description
The AWA14434 measuring microphone is specifically designed for high sound pressure level (SPL) measurements, with a measurement limit exceeding 175 dB. It features excellent stability and environmental adaptability, meeting the Class 1 engineering measuring microphone requirements of SJ/T 10724. It can be used with the AWA8750 adapter and a 1/2-inch preamplifier, or directly with the AWA14614E 1/4-inch preamplifier. Assembly and debugging of the AWA144XX series measuring microphones are performed in a cleanroom, featuring low background noise, high stability, and a wide frequency response range. It can be used with multi-channel analyzers, noise analyzers, electroacoustic testers, and other instruments for noise measurement and analysis, and can also replace measuring microphones from other domestic and international brands.
Product Video
Features
Ultra-high SPL measurement capability: Supports sound pressure levels exceeding 175 dB for extreme acoustic environments.
Wide dynamic range performance: Covers 57 dB to 175 dB, ensuring accurate measurement across high-intensity sound conditions.
Wide frequency response up to 40 kHz: Enables high-frequency and ultrasonic acoustic measurement applications.
Pressure field optimized design: Suitable for high-intensity pressure field measurements with stable acoustic response.
High stability and low drift: Cleanroom assembly ensures consistent performance and long-term measurement reliability.
Wide environmental adaptability: Operates reliably in -30°C to +80°C and 0–100% RH conditions.
Low sensitivity optimized for high SPL: 0.63 mV/Pa sensitivity designed to prevent overload in extreme sound environments.
Multiple preamplifier compatibility: Supports 1/2-inch and 1/4-inch preamplifiers via adapters for flexible system integration.
OEM/ODM customization available. Learn more.
|
AWA14434 Measuring Microphone |
|
|
Sound field type |
Pressure field |
|
diameter |
1 |
|
Dimensions conform to standard (IEC 61094) |
WS3P |
|
Polarization Voltage (V) |
0 |
|
Sensitivity (mV/Pa) (@250 Hz±2.0 dB) |
0.63 |
|
Frequency Range (Hz) |
3.15～40k |
|
Typical Capacitance (pF) (@250Hz) |
3 |
|
Dynamic range (dB) |
57～175 |
|
Background noise (dBA) |
≤57 |
|
Equal pressure method |
Lateral pressure equalization |
|
Operating temperature (℃) |
-30～+80 |
|
Temperature Coefficient (dB/℃) (@250Hz) |
-0.01（-10 ℃～50 ℃） |
|
Static pressure coefficient (dB/kPa) |
-0.005 |
|
Operating humidity range (%RH) |
0～100 |
|
Height (including protective cover) (mm) |
10.4 |
|
Diameter (including protective cover) (mm) |
7 |
|
Height (excluding protective cover) (mm) |
9.1 |
|
Diameter (excluding protective cover) (mm) |
6.35 |
|
Pre amplifier with matching thread |
5.7 mm-60 UNS |
Frequency Response
